Dahua HDCVI 2.0MP Bullet 2.8mm Duall illumination HFW1219X-IL-A-PRO
- High-Quality Imaging with 1080P Resolution
- Smart Dual Light: Built-in IR and LED Lights with 3 Illumination Modes Supported
- 50 m Illumination Distance for Superior Camera Image Quality
- WizColor Technology: Exceptional Image Quality in Low-Light Conditions
- Built-In Dual Mic : Enhances Video Assistance with Dual Mic Technology
- Smart Light+ : Clear Details with Advanced LED Processing Technology
- 3DNR & 130dB WDR & Super Adapt Ensures Clear Details in Strong Backlight Conditions
- Effortless Signal Selection with DIP Switch
- Time-saving Installation with Quick-to-install Structure
- IP67 Ratings for Protection Against Harsh Environments
Specifications
Camera
- Image Sensor : 2 MP CMOS
- Max. Resolution : 1920 (H) × 1080 (V)
- Scanning System : Progressive
- Electronic Shutter Speed : PAL: 1/25 s–1/100,000 s / NTSC: 1/30 s–1/100,000 s
- Min. Illumination : 0.0001 lux@F1.0 (Color, 30 IRE) / 0.00001 lux@F1.0 (B/W, 30 IRE) / 0 lux (Illuminator on)
- S/N Ratio : >65 dB
- Illumination Distance : IR: 50 m (164.04 ft); Warm light: 50 m (164.04 ft)
- Illuminator : On/Off Control Auto/Manual
- Illuminator Number : 4 (Multi-core light)
- Angle Adjustment : Pan: 0°–360° / Tilt: 0°–90° / Rotation: 0°–360°
Lens
- Lens Type : Fixed-focal
- Lens Mount : M12
- Focal Length : 2.8 mm / 3.6 mm
- Max. Aperture : F1.0
- Field of View : 2.8 mm: H: 101.8° / V: 54.4° / D: 122.1° - 3.6 mm: H: 84.2° / V: 45.3° / D: 98.9°
- Iris Control : Fixed
- Close Focus Distance : 2.8 mm: 1.1 m (3.61 ft) - 3.6 mm: 1.6 m (5.25 ft)
Video
- Video Frame Rate : CVI:PAL: 1080p@25 fps / NTSC: 1080p@30 fps / AHD : PAL: 1080p@25 fps / NTSC: 1080p@30 fps / TVI : PAL: 1080p@25 fps / NTSC: 1080p@30 fps / CVBS : PAL: 960H / NTSC: 960H
- Resolution : 1080p (1920 × 1080) / 960H (960 × 576/960 × 480)
- Day/Night : Auto(ICR) / Color / B/W
- BLC : BLC / HLC / WDR
- WDR : 130 dB
- White Balance : Auto
- Gain Control : Auto
- Noise Reduction : 3D NR
- Motion Detection : Yes (It needs to be controlled through the XVR)
- Illumination Mode : Yes (It needs to be controlled through the XVR)
- Mirror : Yes (It needs to be controlled through the XVR)
Certification
- Certifications : CE-LVD: EN 62368-1 / CE-EMC: EN 55032 / EN 55035
Audio
- Built-in Mic : Yes / built-in dual Mic
- Camera Audio : CVI
- Pick-up Distance : 12 m (39.37 ft)
Port
- Video Output : Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)
Power
- Power Supply : 12 VDC (±30%)
- Power Consumption : Max 5.6 W (12 VDC / LED on)
Environment
- Operating Temperature : –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity : <95% (RH), non-condensing
- Storage Temperature : –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity : <95% (RH), non-condensing
- Protection : IP67
- Anti-corrosion : Level Basic Protection (*The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection)
Structure
- Casing Material : Metal front cover + plastic rear barrel + metal bracket
- Product Dimensions : 186.5 mm × 75 mm × 82.2 mm (7.34" × 2.95" × 3.24") (L × W × H)
- Net Weight : 0.35 kg (0.77 lb)
- Gross Weight : 0.49 kg (1.08 lb)
- Installation : Wall mount / ceiling mount / vertical pole mount
31.92 €
31.92 €
31.92 €
